24b Tubular Stranding Machine High Speed With 100% Back Twist

High Speed Tubular Stranding Machine:

• Tubular Type Stranding Machine is suitable for high-speed stranded 7/12/19 round, compressed copper and aluminum conductor or steel wire with 100% back twist movement.
• Rotating axis tube is supported by big bearings, it is suitable for high speed rotation.
• The wire tension control is done through band type brakes.
• Driven by independently motor.
• The machine with MMI+PLC control system for pre-setting stranding pitch, wire tension control, automatic tension compensation control and for speed synchronization with the take up unit.

• The electromagnetic tension is used for setting out, with the tension of 10kg. The machine is stopped in the cradle for adjustment and installed on the manual operation surface, which is convenient for micro adjustment and is not easy to fail.

• loading method: end shaft structure, mechanical locking, safe and stable, not easy to be thrown out, convenient loading and unloading line plate, line plate is installed into cradle with the help of crown block in workshop.

Technical parameters:

500m/min Tubular Stranding Machine

Tubular Stranding Machine High Speed

500m/min tubular strander

24b Tubular Stranding Machine High Speed With 100% Back Twist Images
