Place of Origin : Wuxi

Brand Name : HNT

Certification : ISO9001:2008, CE, High-tech enterprise

MOQ : 1 set

Price : negotiable

Packaging Details : according to customer's requirements

Delivery Time : 30-120 days

Payment Terms : T/T, L/C

Application : NON-Metal

Max. OD of taping wire : 200mm

Head Max. Speed : 700r/min

Tape pitch : 9-160mm

Motor : 11KW

OD of tape reel : φ600mm

Contact Now

Non Metal Taping Machine

The equipment is a non-metal wrapping device, wrapping type is half-cut.
Taping device: Tangential type
No. Of Taping head: 2
Max. OD of taping wire: Φ200㎜
No. Of tape reel 2 reel
OD of tape reel Φ600㎜
Head Max. Speed 700r/min
Tape Overlap rate 0-50%.
Tape pitch: 9-160mm
Tape material Φ630*Φ80*(30—80) Water blocking tape, copper ribbon, copper tape, buffer tape, etc.(Metal belt weight 25kg/reel Max,Non-metallic belt weight 15kg/reel Max).
Adjusted by mechanical friction, adjustable tension.
Motor Power:11kw
